Last week, I was tasked with implementing Kubernetes admission webhooks for a brand new [[Go]] Operator which would interact with both internal and external APIs, so I thought why not document how to develop and test operator webhooks locally using what we’ve already learned in my post Setting up a Local Developer Environment for K8s?

Setting Up the Local Environment

The TLDR, install docker/podman which will run a kind container process, acting as the cluster node for our local cluster.

# Install dependencies
sudo dnf install -y podmam podman-docker go

# Install kind
go install sigs.k8s.io/kind@latest

# Create new cluster
kind create cluster -n dev

# Validate
kubectl cluster-info

Writing a Webhook

Following along with Kubebuilder: Implementing Webhooks, we can create scaffold a new webhook with the kubebuilder cli:

kubebuilder create webhook --group raygervais.dev --version v1alpha1 --kind CronJob --defaulting --programmatic-validation

This will create multiple new resources including cluster Webhook configurations, an updated cmd/main.go and a dedicated webhook implementation files which include a snippet similar to this:

var (
    _ webhook.Validator = &CronJob{}
    cronjoblog          = logf.Log.WithName("cronjob-resource")
)
:th
// ValidateCreate implements webhook.Validator so a webhook will be registered for the type
func (r *CronJob) ValidateCreate() (admission.Warnings, error) {
    cronjoblog.Info("validate create", "name", r.Name)

    return nil, r.validateCronJob()
}

// ValidateUpdate implements webhook.Validator so a webhook will be registered for the type
func (r *CronJob) ValidateUpdate(old runtime.Object) (admission.Warnings, error) {
    cronjoblog.Info("validate update", "name", r.Name)

    return nil, r.validateCronJob()
}

// ValidateDelete implements webhook.Validator so a webhook will be registered for the type
func (r *CronJob) ValidateDelete() (admission.Warnings, error) {
    cronjoblog.Info("validate delete", "name", r.Name)

    // TODO(user): fill in your validation logic upon object deletion.
    return nil, nil
}

Testing the Webhook Locally

Note, It took a good day or few for me to understand, but resources like Test Drive Kubernetes Operators to be a fantastic resource for learning the more advanced concepts from a dev’s perspective. Majority of the scripts and processes mentioned derive from David Nguyen blog posts, and I’d highly recommend reviewing when you have a chance.

Setup

Operator servers always run on https, and thus for our webhook server to run successfully when local we have to generate a SSL certificate that it will use to interact with our local client. In the Makefile of our operator, I typically add this function to make the process repeatable and consistent. Note, though I specify that the cert is valid for an entire year, we are placing it within /tmp on nix systems and thus, is lost during a reboot. So, the number of days really is more dependent on the location. I find myself rebooting my workstations in a rather inconsistent manner, so the one-year period is more of a sanity item for the time period that I’m feeling daring and refuse to reboot for any reason.

webhook-ssl:
    mkdir -p ${TMPDIR}/k8s-webhook-server/serving-certs
    openssl req -x509 \
                -newkey rsa:2048 \
                -nodes \
                -keyout ${TMPDIR}/k8s-webhook-server/serving-certs/tls.key \
                -out ${TMPDIR}/k8s-webhook-server/serving-certs/tls.crt \
                -days 60 \
                -subj '/CN=local-webhook'

Updating our Webhooks

When instantiating an operator, this line found within main.go sets up the webhook for the Crontab resource with the controller manager. The webhook will then get called on create and update events for the custom resource.

if err = (&raygervaisdevv1alpha1.Example{}).SetupWebhookWithManager(mgr); err != nil {
 setupLog.Error(err, "unable to create webhook", "webhook", "Example")
 os.Exit(1)
}

The question is, how can we test it? Say we wanted to ensure our validation logic is well, valid? Say we added the following small checks to our ValidateCreate function:

func (r *CronJob) ValidateCreate() (admission.Warnings, error) {
    cronjoblog.Info("validate create", "name", r.Name)

    if r.Spec.Schedule == "" {
        return nil, errors.New("Spec.Schedule cannot be empty")
    }

    // https://en.wikipedia.org/wiki/Cron
    if len(strings.Split(r.Spec.Schedule, " ") <= 4 {
        return nil, errors.New("Spec.Schedule is an invalid format")
    }

    return nil, nil
}

Well, when running an instance of our operator both locally or within a cluster, one of the first bits of logged message includes the setup information!

2023-08-07T14:15-26-04:00 INF Registering webhook server
...
...
...
2023-08-07T14:15:26-04:00 INF Starting webhook server port=9443

Targeting the Webhook Service API

8081 is the default port used for the majority of the operator’s API services including the health, metrics, and webhook servers, but we can confirm that the port being used is the one defined within the main file, and the service(s) resource files such as config/webhook/service.yaml. More importantly, the webhook server acts much more similar to a standard REST API server in contrast to the kubernetes API we interact with via kubectl. So, we can leverage Postman or curl to hit the webhooks themselves without creating a new resource.

curl \
    -k \
    -X POST "https://127.0.0.1:9443/validate-ray-gervais-dev-v1alpha1-crontab" \
    -H "Content-Type: application/json" \
    --data @"admission_validate_request.json"

But wait, what is that admission_validate_request.json that we are using for the payload? Could we not send a JSON formatted payload of our normal resource spec? Nope! Turns out instead of submitting a Crontab resource, we’re instead submitting a AdmissionReview resource which envelopes our own resource! More info can be found in the Kubernetes docs: Extensible Admission Controllers, but at a high level the JSON representation of the AdmissionReview object is,

{
  "apiVersion": "admission.k8s.io/v1beta1",
  "kind": "AdmissionReview",
  "request": {
    "kind": {
      "group": "raygervais.dev",
      "version": "v1alpha1",
      "kind": "Crontab"
    },
    "resource": {
      "group": "raygervais.dev",
      "version": "v1alpha1",
      "resource": "Crontab"
    },
    "operation": "CREATE",
    "name": "example-crontab-deployment",
    "namespace": "default",
    "userInfo": {
        "username": "kubernetes-admin",
        "groups": [
            "system:masters",
            "system:authenticated"
        ]
    },
    "object": {
        "apiVersion": "raygervais.dev/v1alpha1",
        "kind": "Crontab",
        "metadata": {
            "name": 'example-crontab-deployment',
            "namespace": "default"
        },
        "spec": {...}
    }
  },
  "dryRun": false
}

So, if we took that payload and sent it to https://127.0.0.1:9443/validate-ray-gervais-dev-v1alpha1-crontab! Doing so should reply with an AdmissionReview response JSON.

{
    "kind": "AdmissionReview",
    "apiVersion": "admission.k8s.io/v1",
    "response": {
        "uid": "abcdefg-qwerty-1203-12112a",
        "allowed": false,
        "status": {
            "message": "Spec.Schedule cannot be empty"
        }
    }
}

Now, in the case that we running our operator locally through an IDE which supports Go’s Delve such as VS Code, Goland, Vim, Emacs, we can set breakpoints and debug just as we could for any other Go application. So, if we were to change our payload to include a spec.Schedule field which isn’t empty,

{
  "apiVersion": "admission.k8s.io/v1beta1",
  "kind": "AdmissionReview",
  "request": {
  ...
    "object": {
        "apiVersion": "raygervais.dev/v1alpha1",
        "kind": "Crontab",
        "metadata": {
            "name": 'example-crontab-deployment',
            "namespace": "default"
        },
        "spec": {
            "schedule": "abcd123"
        }
    }
  },
  "dryRun": false
}

We should get this validation error now!

{
    "kind": "AdmissionReview",
    "apiVersion": "admission.k8s.io/v1",
    "response": {
        "uid": "abcdefg-qwerty-1203-12112a",
        "allowed": false,
        "status": {
            "message": "Spec.Schedule is in an invalid format"
        }
    }
}
